Honeywell Vigilon 4 loop User Manual

IO domain bridge network switch settings
Commissioning instructions
94 4188-856_issue 7_07/15_Generic Vigilon (Compact + VA) Comms.
Multiple Vigilon Networks
Domain 2
Node 1
Node 3
Node 2
Control panel
Network Card
Address 2
Baud 38.4K
Control panel
Network Card
Address 3
Baud 38.4K
Control panel
Network Card Address 1 Baud 38.4K
IO Card
all switches to
Off position
IO Card
all switches to
Off position
DKC
Address 2
Baud 19.2K
DKC
Address 2
Baud 19.2K
IO Card
all switches to
Off position
DKC
Address 2
Baud 19.2K
Switch settings on cards inside
EN54 Vigilon panels / Nodes
where Domain Bridge IO Card
is used to network the fire systems
Domain Bridge
Domain 1
IO Card switches must be set to Off,
these are now located on the DKC.
Node 1
Node 3
Node 2
Control panel
Network Card
Address 2
Baud 38.4K
Control panel
Network Card
Address 3
Baud 38.4K
Control panel
Network Card
Address 1
Baud 38.4K
IO Card
all switches to
Off position
IO Card
all switches to
Off position
DKC
Address 1
Baud 19.2K
DKC
Address 1
Baud 19.2K
IO Card
all switches to
Off position
DKC
Address 1
Baud 19.2K
Network card address setting is for the
Domain Bridge IO Card address setting is for the
Node address
Domain address
Baud rate settings must be set as shown in this diagram.
