Honeywell Vigilon 4 loop User Manual

4188-856_issue 7_07/15_Generic Vigilon (Compact + VA) Comms. 153
Vigilon 4/6 loops & Compact (VA) panels & network nodes
Appendix C - Guidelines for standalone system commands
Sounders Configuration
¨
The standard alarm devices of each standalone system can be configured for three
sound output signals
¨
every 250mS over a 2 second time the sound output can be altered to high, low or off
tone
¨
sound signal configuration can be altered by modifying the FAB-SAB pairs by
pressing the button Menu On/Off to select [Set-Up] -> <etc-> -> [Modify]-> <etc>
-> [Signal n] -> [Sounder] -> [Enter] and enter the FAB/SAB for Signal n and press
enter.
FABs & SABs
The FAB (first action byte) determines tone and On/Off control while the SAB (second action byte)
determines the action to be performed on the output.
Factory Default FABs
SABs
Time in seconds
0 0.25 0.5 0.75 1.0 1.25 1.5 1.75
Signal 3 (Continuous)
Output turns on Low
frequency sound
continuous every 0.5
seconds.
4F 00 4F 00 4F 00 4F 00
Signal 2 (Evacuate)
First output turns on
Low frequency sound
continuously, then every
half second the High
frequency output is
pulsed for 250mS.
4F 25 4F 25 4F 25 4F 25
Signal 1 (Alert)
Pulses high frequency
for 250mS every half
second.
65 00 65 00 65 00 65 00
Number FAB action SAB action
0 no output
Turns Off selected Outputs
1 - 10mS pulse on selected Outputs
2 frequency tone 40mS pulse on selected Outputs
3 - 90mS pulse on selected Outputs
4
On/Off control.(On being low
frequency)
160mS pulse on selected Outputs
5 - 250mS pulse on selected Outputs
6 high frequency tone 350mS pulse on selected Outputs
7 - 480mS pulse on selected Outputs
8 - 630mS pulse on selected Outputs
9 - 800mS pulse on selected Outputs
A - 980mS pulse on selected Outputs
B - 1.2S pulse on selected Outputs
C - 1.4S pulse on selected Outputs
D - 1.6S pulse on selected Outputs
E 1.9S pulse on selected Outputs
F Turn on selected Outputs
Appendix C - Guidelines forAppendix C - Guidelines forAppendix C - Guidelines forAppendix C - Guidelines for standalone system commands
