S-Quad Sensors (Legacy product range)
The following S-Quad sensors when operating in the STATES shown in table below are LPCB approved to the respective standard.
Product number Description Standard
S4-720-ST-VO Heat sensor Strobe and Speech (Speech and Strobe - no approval) EN54 : Part 5 :2002* - (heat)
S4-780
S4-780-ST
Heat Sensor plus Sounder
Heat Sensor plus Sounder & Strobe (Strobe - no approval)
EN54 : Part 5 : 2002* - (heat)
EN54 : Part 3 : 2001 - (sounder)
S4-711-ST Dual Optical & Heat Sensors Strobe (Strobe - no approval) EN54 : Part 7 : 2000* (optical smoke)
EN54 : Part 5 : 2002* (heat)
CEA 4021 : 2003-07 Class P heat multisensor detector
S4-911 Dual Optical, Heat & CO Sensors (CO - no approval)
S4-711-ST-VO Dual Optical & Heat Sensors, Speech & strobe (Speech and Strobe - no approval) EN54 : Part 7 : 2000* (optical smoke)
EN54 : Part 5 : 2002* (heat)
EN54 : Part 3 2001 - (sounder tone)
CEA 4021 : 2003-07 Class P heat multisensor detector
S4-711-VO Dual Optical & Heat Sensors, Speech (Speech - no approval)
S4-771 Dual Optical & Heat Sensors & Sounder
S4-911-ST-VO Dual Optical, Heat & CO Sensors, Speech & Strobe
(Speech, Strobe & CO - no approval)
S4-770 Optical & Heat sensors and Sounder
* - these standards are met when the sensor is operating LPCB approved STATES, see STATES table below. Sounder tone description - see next page
"
If a S-Quad sensor is configured to operate a non LPCB STATE, then this will contravene the LPCB approval. The required STATE is configured during commissioning and
can be also configured using controls at the main panel.
4188-856_issue 7_07/15_Generic Vigilon (Compact + VA) Comms. 15
Vigilon 4/6 loops & Compact (VA) panels & network nodes
Product Approval and Standards
