S-Quad Sensor with VAD - STATES VAD (current range of devices)
The STATE in which an S-Quad sensor operate can be changed from the default factory set STATE to another STATE during commissioning using the Commissioning tool. The environment in which
an S-Quad device is installed will determine what STATE is used. # - Factory Default STATE ~ EN54 : Part 7 :2000 * EN54 : Part 5 :2002
&
The S-Quad with VAD devices are compatible with control panel software (MCC/MCB equal to or greater than V4.52 and LPC equal to or greater than V4.48).
# - factory default settings
Device
LPCB
approved
STATE
Meets ~ EN54-7 : 2000, A1:2002, A2:2006
* EN54-5 : 2000, A1:2002
Dual Optical & Heat sensor variant - S4-711
(With VAD) S4-711-VAD-HPR
S4-711-VAD-LPW
S4-711-VAD-HPW
(With Speech) S4-711-V
(With VAD & Speech) S4-711-V-VAD-HPR
S4-711-V-VAD-HPW
(With Sounder) S4-771-S
STATE 0 # Medium optical smoke ~ / Class A1 heat *
STATE 5 Medium optical smoke ~ / Class B heat *
STATE 8 Delayed medium optical smoke ~ / Class A1 heat*
Dual Optical, Heat & CO sensor variant-
S4-901
(With Speech & VAD) S4-911-V-VAD-HPR
S4-911-V-VAD-HPW
STATE 0 # Medium optical smoke ~ / Class A1 heat *
STATE 9 Class A1 heat *
Optical & Heat sensor variant -
S4-710
(With Sounder) S4-770-S
STATE 0 # Medium optical smoke ~ / Class A1 heat*
Heat sensor variant - S4-720
(With Speech VAD) S4-720-V-VAD-HPR
S4-720-V-VAD-HPW
(With Sounder) S4-780-S
STATE 0 # Class A1 heat *
STATE 5 Class B heat *
Optical sensor S4715
STATE 0 Medium optical smoke
All of the above S-Quad range of devices meet EN54-17:2005 Short circuit isolation plus EN54-18:2005 Input/Output devices for use on the transmission path of fire detection and alarm systems.
4188-856_issue 7_07/15_Generic Vigilon (Compact + VA) Comms. 73
Vigilon 4/6 loops & Compact (VA) panels & network nodes
S-Quad Sensor with VAD - STATES VAD (current range of devices)
