126
Ste
Command
Remarks
6. Specify the FTP operation
type.
operation { get | put }
By default, the FTP operation type is get,
which means obtaining files from the FTP
server.
7. Specify an FTP login
username.
username username
By default, no FTP login username is
configured.
8. Specify an FTP login
password.
password { cipher | simple }
password
By default, no FTP login password is
configured.
9. (Optional.) Specify the
name of a file to be
transferred.
filename file-name
By default, no file is specified.
This step is required if you perform the put
operation.
10. Set the data transmission
mode.
mode { active | passive } The default mode is active.
Configuring the HTTP operation
An HTTP operation measures the time for the NQA client to obtain data from an HTTP server.
To configure an HTTP operation:
Ste
Command
Remarks
1. Enter system view.
system-view N/A
2. Create an NQA operation
and enter NQA operation
view.
nqa entry admin-name
operation-tag
By default, no NQA operation is created.
3. Specify the HTTP type and
enter its view.
type http N/A
4. Specify the URL of the
destination HTTP server.
url url
Enter the URL in one of the following
formats:
• http://host/resource.
• http://host:port/resource.
5. Specify an HTTP login
username.
username username
By default, no HTTP login username is
specified.
6. Specify an HTTP login
password.
password { cipher |
simple } password
By default, no HTTP login password is
specified.
7. (Optional.) Specify the source
IP address of request packets.
source ip ip-address
By default, no source IP address is
specified.
The source IP address must be the IP
address of a local interface, and the
interface must be up. Otherwise, no
request packets can be sent out.
8. Specify the HTTP operation
type.
operation { get | post |
raw }
By default, the HTTP operation type is get,
which means obtaining data from the HTTP
server.
9. Specify the HTTP version.
version { v1.0 | v1.1 } By default, HTTP 1.0 is used.
