HP 5920 Configuration Guide

178
• A remote probe VLAN must be a static VLAN. To delete this static VLAN, you must first remove the
remote probe VLAN configuration by using the undo mirroring-group remote-probe vlan
command.
• If the remote probe VLAN of a remote mirroring group is removed, the remote mirroring group will
become invalid.
Configuration procedure
To configure local port mirroring with multiple monitor ports:
Ste
p
Command Remarks
1. Enter system view.
system-view N/A
2. Create a remote source
group.
mirroring-group group-id
remote-source
By default, no mirroring groups exist
on a device.
3. Configure source ports
for the remote source
group.
• In system view:
mirroring-group group-id
mirroring-port mirroring-port-list
{ both | inbound | outbound }
• In interface view:
a. Enter interface view:
interface interface-type
interface-number
b. Assign the port to the mirroring
group as a source port:
mirroring-group group-id
mirroring-port { both |
inbound | outbound }
c. Return to system view:
quit
By default, no source port is
configured for a mirroring group.
4. Configure the reflector
port for the remote
source group.
mirroring-group group-id reflector-port
reflector-port
By default, no reflector port is
configured for a mirroring group.
5. Create a VLAN to be
configured as the
remote probe VLAN.
vlan vlan-id
By default, only VLAN 1 (system
default VLAN) exists.
6. Assign monitor ports to
the VLAN.
port interface-list By default, all ports are in VLAN 1.
7. Return to system view.
quit N/A
8. Configure the VLAN as
the remote probe VLAN
for the remote source
group.
mirroring-group group-id
remote-probe vlan rprobe-vlan-id
By default, no remote probe VLAN is
configured for a mirroring group.
Configuring Layer 2 remote port mirroring
Configuring Layer 2 remote port mirroring is to configure remote mirroring groups. When doing this,
configure a remote source group on the source device and a cooperating remote destination group on
the destination device. If intermediate devices exist, configure the intermediate devices to allow the
remote probe VLAN to pass through.
