HP 5920 Configuration Guide

143
In TCP template view, you can specify the expected data to be returned. If you do not specify the
expected data, the TCP operation only tests whether the client can establish a TCP connection to the
server.
The TCP operation requires both the NQA server and the NQA client. Before you perform a TCP
operation, configure a TCP listening service on the NQA server.
To configure the TCP template:
Ste
p
Command Remarks
1. Enter system view.
system-view N/A
2. Create a TCP template and
enter its view.
nqa template tcp name N/A
3. (Optional.) Specify the
destination IPv4 or IPv6
address of the operation.
• IPv4 address:
destination ip ip-address
• IPv6 address:
destination ipv6 ipv6-address
By default, no destination
address is specified.
The destination address must be
the same as the IP address of the
listening service configured on
the NQA server.
4. (Optional.) Configure the
destination port number for the
operation.
destination port port-number
By default, no destination port
number is configured.
The destination port number must
be the same as the port number
of the listening service on the
NQA server.
5. (Optional.) Specify the string to
be filled in the payload of each
request.
data-fill string
The default setting is the
hexadecimal number
00010203040506070809.
6. (Optional.) Specify the source
IPv4 or IPv6 address for the
probe packets.
• IPv4 address:
source ip ip-address
• IPv6 address:
source ipv6 ipv6-address
By default, no source IP address
is specified.
The source IP address must be
the IP address of a local
interface, and the interface must
be up. Otherwise, no probe
packets can be sent out.
7. (Optional.) Configure the
expected data.
expect data expression [ offset
number ]
By default, no expected data is
configured.
The expected data is checked
only when you configure both
the data-fill command and the
expect-data command.
Configuring the HTTP template
A feature that uses the HTTP template creates and starts the HTTP operation to measure the amount of
time it takes for the NQA client to obtain data from an HTTP server.
The expected data is checked only when the expected data is configured and the HTTP response
contains the Content-Length field in the HTTP header. The Content-Length field indicates the packet body
