6. Unplug the mating connector.
To replace the component, reverse the removal procedure.
Removing and replacing the system board
IMPORTANT: If your system board has a TPM installed, you must order a new TPM when you
order a replacement system board.
Before replacing the system board, you must first back up the current TPM settings. See the HP-UX
operating system documentation for more information.
The TPM is not a customer-installable component. If you need to replace a TPM on a replacement
system board, contact an HP authorized service provider.
WARNING! After the TPM is installed on your system board, it cannot be removed. If the TPM
fails, the system board must be replaced. Attempting to remove the TPM from the system board
will void any existing HP service contract and cause the server to fail.
1. Power off the server (“Powering off the server” (page 94)).
2. Remove all power supplies (“Removing and replacing a hot-swap power supply” (page 98)).
3. Remove all hot-plug hard drives (“Removing and replacing a hot-plug SAS hard drive” (page
97)).
4. Extend or remove the server from the rack (“Removing the server from the rack” (page 95))
or “Extending the server from the rack” (page 93)).
5. Remove the access panel (“Removing and replacing the access panel” (page 99)).
6. Remove the air baffle.
Removing and replacing the system board 119
