Table 19 Rear panel LEDs and buttons
StatusName
Power supply LED
• Green = Normal
• Off = System is off or power supply has failed
UID LED/button
• Blue = Identification
• Flashing blue = Remote iLO session or a firmware flash update is in progress
• Off = Off
NIC/iLO 3 activity LED
• Green = Network activity
• Flashing green = Network activity
• Off = No network activity
NIC/iLO 3 link LED
• Green = Network link
• Off = No network link
The iLO 3 physical presence button enables you to reset iLO 3 and gain access to the system
if all iLO passwords are lost. A momentary press causes a soft reset of iLO 3 when the button
iLO 3 physical presence
pinhole button
is released. The iLO 3 Physical Presence button enables you to reset iLO, enter TPM physical
presence mode, and enter security override mode.
• A momentary press of the button resets iLO, clears any security override or TPM physical
presence mode that were initiated by this button, and returns the serial port to iLO mode.
• A greater than 4-second and less than 8-second press of the button places the system in
physical presence mode for up to 15 minutes.
• A greater than 8-second and less than 12-second press of this button places iLO into
security override mode for up to 15 minutes. Security override mode enables you to enter
iLO without being challenged for a password enabling you to set up users.
• The UID LED blinks once after holding the button for 4 seconds and once after holding
the button for 8 seconds to help you gauge how long the button press has been held.
NOTE: The iLO 3 physical presence pinhole button is located behind the sheet metal grill
and the circular punch-out in the rear panel.
Power supply
The server is equipped with two power supplies, labeled PS1 and PS2. Each power supply has a
DC power input receptacle and an LED that indicates the power state of the server.
The server has the following power states: standby power, full power, and off. To achieve the
standby power state, plug the power cord into the appropriate receptacle at the rear of the server.
To achieve full power, plug the power cord into the appropriate receptacle, and either push the
power button or enter the iLO 3 MP PC command. In the off state, the power cords are not connected
to a power source.
Table 20 Power supply LED states
IndicationLED state
No DC powerOff
Full power on; normal operationGreen
Diagnostics
A suite of offline and online support tools are available to enable manufacturing, field support
personnel, and the customer to troubleshoot system issues. In general, if the operating system is
already running, then HP recommends that you do not shut it down and instead, use the online
support tools.
Troubleshooting tools 71
