Product specifications
The following table lists the physical dimensions.
Table 1-4 Physical characteristics
Weight (depending on
configuration)
18 - 25.2 kg (39.6 - 55.6 lb.)
Tower dimensions 455 mm (17.9 in.) tall, 210 mm (8.3 in.) wide, 525 mm (20.7
in.) deep
Rack mount dimensions (top
cover and foot removed)
210 mm (8.3 in.) tall, 440 mm (17.3 in.) wide, 525 mm (20.7
in.) deep
Power supply and cooling
This section describes power supply specifications.
Table 1-5 Voltage specification
Voltage Minimum Maximum Description
3.3 V 3.17 V 3.47 V Used with PCI, MCH, ESB2, PXH, LAN, and onboard logic
5 V 4.90 V 5.35 V Used with storage (disk, optical, diskette), PCI, Audio,
USB, input to onboard regulator, and onboard logic
12 VCPU0 11.52 V 12.6 V Input to onboard regulator that supplies power for CPU0
12 VCPU1 11.52 V 12.6 V Input to onboard regulator that supplies power for CPU1
12 V-M 11.52 V 12.6 V Input to onboard regulators that supply 1.5 V and 1.8 V
for memory
12 V-B 11.52 V 12.6 V Used with PCI fans, input to onboard regulators that
supply 1.5 V and 1.2 V
12 V-D 11.52 V -12.6 V Used with storage (disk, optical, floppy)
12 V-G 11.52 V 12.6 V Used with PCI Express x16 auxiliary connector
V12N –11.4 V –12.6 V Used by PCI
5 VSB 4.85 V 5.25 V Used for sleep circuitry
Table 1-6 Current specification
Current Minimum Operating Continuous Maximum Description
3.3 V 0 A 0.5 A 22.0 A 25.0 A Used with PCI, MCH, ESB2, PXH, LAN, and
onboard logic
5 V 0 A 0.5 A 18.0 A 20.0 A Used with storage (disk, optical, diskette), PCI,
Audio, USB, input to onboard regulator, and
onboard logic
12 VCPU0 0 A 3.1 A 13.7 A 16.8 A Input to onboard regulator that supplies power for
CPU0
6 Chapter 1 Product overview ENWW
