Ultra ATA jumpers
NOTE This system supports a mixed configuration of UATA/IDE optical drives, and SAS and
SATA hard drives. While HP supports the presence of SCSI and IDE hard drives, it does not ship
any configurations using those drives.
Ultra ATA drives are configured with jumper settings. Factory-installed drives ship with the jumpers
preset to the cable-select mode; therefore, no jumper setting changes are required on factory
preinstalled, replacement, or option drives. With cable-select, the drive is configured as either Master
(Drive/Device 0) or Slave (Drive/Device 1) by its physical attachment to the cable.
If you purchase a third-party hard drive, refer to the documentation included with the drive kit to ensure
proper cable installation and configuration.
NOTE All drives on a controller channel must have their jumpers either in the cable-select mode
or have the individual drive jumper installed on the appropriate Master (Drive/Device 0) or Slave
(Drive/Device 1) position.
144 Appendix C Appendix C — Ultra ATA devices ENWW
