HP XW8400 User Manual

WARNING! Before removing the workstation access panel, be sure that the workstation is
powered off and that the power cord is disconnected from the electrical outlet.
1. Disconnect power from the system.
2. If a lock is present, unlock the access panel. The keys are on the rear panel (
Rear panel
components on page 4). Also, unlock any other locks that are present (Kensington, or Padlock).
3. Pull up on the handle and lift off the cover.
Figure 4-5 Opening the access panel
To replace the access panel, slide the cover back on until it snaps into place.
Front bezel
To remove the front bezel:
1. Lift up on the three (1) tabs located on the front bezel.
2. Rotate the front bezel away (2) from the chassis, and remove the bezel.
ENWW Removing and replacing components 59

HP XW8400 Specifications

General

Processor Speed	Up to 3.0 GHz
Chipset	Intel 5000X
Power Supply	800W
Form Factor	Tower
Processor	Intel Xeon (Dual-core or Quad-core)
Memory	Up to 32 GB DDR2
Storage	SATA or SAS Hard Drives
Graphics	NVIDIA Quadro
Expansion Slots	2 PCI Express x16, 2 PCI
Operating System	Windows XP Professional
Optical Drive	DVD-ROM
USB Ports	7 USB 2.0
Network	Integrated Gigabit Ethernet
