INFICON Product Overview | 5
074-594-P1H Micro GC Fusion Operating Manual 45 / 319
5.10.2 Sample Inlet
Sample Inlet Specification
Front inlet Heated, 30-140°C (86-284°F), 1/16 in.
Swagelok
Maximum sample pressure 172 kPa (25 psi)
Recommended sample pressure Ambient to 69 kPa (10 psi)
5.10.3 Integrated Sample Conditioner
Integrated Sample Conditioner Specification
Front inlet Heated, 100°C (212°F), 1/8 in. quick
connect
Maximum sample pressure 6,895 kPa (1,000 psi)
Minimum sample pressure 34.5 kPa (5 psi) suggested for optimal
purging
5.10.4 Gas Liquid Separator
Gas Liquid Separator Specification
Sample inlet 1/16 in. Swagelok
Maximum sample pressure 172 kPa (25 psi)
5.10.5 Pressure Reducer and Gas Liquid Separator
Pressure Reducer and Gas Liquid Separator Specification
Sample inlet 1/8 in. Swagelok
Maximum sample pressure 3,450 kPa (500 psi)
5.10.6 Sample Injector
Sample Injector Specification
Variable volume Heated, 1 to 10 uL
Variable large volume Heated, 1 to 30 uL
Fixed volume Heated, 1.6 uL
Backflush to vent Heated, 0.4 or 1 uL fixed, 7.1 uL maximum variable
