INFICON Installation | 6
074-594-P1H Micro GC Fusion Operating Manual 73 / 319
ð Repeat the previous step to finish securing the remaining nuts on the left
bracket.
ð To attach the right bracket (PN 952-4005-P2), repeat step 3.
4
Once both brackets are secure, gently place Micro GC Fusion onto rack mount
brackets.
5
Line up the holes on the bottom of the unit to the holes in the brackets.
6
Secure the instrument on the brackets with the provided flat Phillips head screw
(PN 090-062).
7
Micro GC Fusion is now attached to the rack.
