SERVICE INFORMATION 00 – 13

4. SLAPPING NOISE

Checkpoint Possible cause Correction

Valve clearance Valve clearance improperly adjusted Adjust the valve clearance

Rocker arm Damaged rocker arm Replace the rocker arm

Flywheel Loose flywheel bolts Retighten the flywheel bolts

Crankshaft and thrust

bearings

Worn or damaged crankshaft and/or thrust

bearings

Replace the crankshaft and/or the

thrust bearings

Crankshaft and

connecting rod

bearings

Worn or damaged crankshaft and/or

connecting rod bearings

Replace the crankshaft and/or the

connecting rod bearings

Connecting rod

bushing and piston pin

Worn or damaged connecting rod bushing

and piston pin

Replace the connecting rod bushing

and/or the piston pin

Piston and cylinder

liner

Worn or damaged piston and cylinder liner. Replace the piston and the cylinder

liner.
