ENGINE COOLING 6B - 11

INSTALLATION

4. Thermostat

3. Gasket

2. Outlet Pipe

• Connect outlet pipe and tighten bolts to the specified

torque.

N∙m (Kg∙m/lb∙ft)

19 (1.9/14)

1. Switch Harness

• Install switch harness.

• Install battery ground cable.

• Pour coolant.

• Start the engine and check coolant leakage.

6B-10-1.tif
