4JB1/4JB1T/4JB1TC/4JG2 – ENGINE 6A1 – 63

CAMSHAFT AND TAPPET

REMOVAL

Preparation:

• Disconnect battery ground cable.

• Drain coolant.

• Drain engine oil.

NOTE

Install drain plug with new washer.

Drain Plug Torque N∙m (kg∙m/lb∙ft)

83 (8.5/61)

6A1-63-1.tif

Removal steps

1. Transmission and clutch

Assembly

2. Engine Assembly

3. Cylinder head Assembly and

gasket

4. Timing gear

(Gear drive model)

4a. Timing belt

(Belt drive model)

5. Oil pan

6. Oil pump

7. Camshaft and tappets

Installation steps

To install, follow the removal

steps in the reverse order.
