9. Aach the rear-mounng blades to the rear post by using the appropriate screws for your rack.

Tighten the screws.

Figure 75: Chassis Fully Installed in the Rack

10. Ensure that the switch chassis is level by verifying that all the screws on the front of the rack are

aligned with the screws at the back of the rack.

Mount an EX4100 and EX4100-F Switch in a Recessed Posion in a Rack

or Cabinet

You can mount an EX4100 and EX4100-F switch in a rack or cabinet such that the switch is recessed

inside the rack from the front of the rack by 2 inches. You can use the 2-in.-recessed front-mounng

brackets provided in the separately orderable four-post rack-mounng kit to mount the switch in a

recessed posion.

Reasons that you might want to mount the switch in a recessed posion include:

• You are mounng the switch in a cabinet, and the cabinet doors do not close completely unless the

switch is recessed.

• The switch you are mounng has transceivers installed in the uplink ports, and the transceivers in the

uplink ports protrude from the front of the switch.

Before you mount an EX4100 and EX4100-F switch in a recessed posion inside a 19-in. four-post rack:

• Verify that the site meets the requirements described in "EX4100 and EX4100-F Site Guidelines and

Requirements" on page 87.

• Place the rack in its permanent locaon, allowing adequate clearance for airow and maintenance,

and secure it to the building structure.
