6. Tighten all mounng screws.
Figure 83: Mounng the Switch on a Wall
Connect the EX4100 and EX4100-F to Power
IN THIS SECTION
Connect Earth Ground to an EX4100 and EX4100-F Switch | 137
Connect AC Power to an EX4100 and EX4100-F Switch | 139
Connect DC Power to an EX4100 Switch | 142
136
