Remove a Fan Module from an EX4100 Switch
Ensure that you have the following parts and tools available:
• Phillips (+) screwdriver, number 2
• An anstac bag or an anstac mat
• A replacement fan module
Each fan module in an EX4100 switch is a hot-removable and hot-insertable eld-replaceable unit (FRU)
installed in the rear panel of the switch. You can remove and replace the switch without powering it o
or disrupng switch funcons.
NOTE: If you remove both fan modules, you must replace at least one fan module within 30
seconds for the switch to operate without disrupng its funcons.
1. Place the anstac bag or the anstac mat on a at, stable surface.
2. Hand loosen the capve screws on the front faceplate of the fan module. If you are unable to hand
loosen the capve screws, use the screwdriver.
WARNING: To prevent injury, avoid touching the fan with your hands or any tools as
you slide the fan module out of the chassis. The fan might sll be running.
3. Grasp the handle on the fan module and pull it rmly to slide the fan module out of the chassis.
4. Place the fan module in the anstac bag or on the anstac mat on a at, stable surface.
5. Install the replacement fan.
182
