OTHER EQUIPMENT
DUST INDICA
TOR
This device notifies the operator of clogging of air cleaner ele-
ment.
DOOR OPEN LOCK
Use the door lock to fix the door in position after opening it.
1.
Push the door against the door catch (1).
The door is fixed to the catch.
2.
When releasing the door, move lever (2) in the cab toward the front inside the cab.
The catch releases.
NOTICE
• When
keeping the door open, fix it securely to the
catch.
• Always close the door when traveling or performing
operations. If doors are left open, they may be broken.
• Lock the doors securely. The doors may be closed by
vibration.
OPERATION EXPLANATION OF COMPONENTS
3-107
