1.
Remove
the cap (2) at the top of the battery and check the
electrolyte level through electrolyte filler port (3).
2.
If the electrolyte does not reach the sleeve (4), always add
the purified water (such as a commercial battery fluid) so
that the level reaches the bottom of the sleeve (UPPER
LEVEL line).
(A) Correct level: Electrolyte level is up to bottom of
sleeve, so surface tension causes electrolyte surface to
bulge and pole plate appears to be warped.
(B) Low level: Electrolyte level does not reach the bottom
of sleeve, so pole plate appears straight and not to be
warped.
3.
After adding the purified water, tighten the cap (2) securely.
REMARK
If the purified water is added to above the bottom tip of the sleeve, use a syringe to remove the electrolyte. Neu-
tralize the removed electrolyte with baking soda (sodium bicarbonate), then flush it away with a large amount of
water. If necessary, consult your Komatsu distributor or a battery manufacturer.
METHOD FOR CHECKING ELECTROLYTE LEVEL ON INDICATOR ETC
If it is possible to use an indicator to check the electrolyte level, follow the instructions given.
METHOD FOR CHECKING BRAKE PERFORMANCE
WARNING
If the machine moves off during the following operation, ask your Komatsu distributor for repairs imme-
diately
.
NOTICE
• Never set the joystick (steering, directional and gear shift lever) to the 1st speed. This will cause
damage to the machine.
• Select the manual shift mode for the gear shift mode.
Before starting the engine, check the safety around the machine, and then perform the following operation.
1.
Start the engine.
MAINTENANCE PROCEDURE MAINTENANCE
4-50
