METHOD FOR REPLACING FUEL TANK BREATHER ELEMENT
1.
Remove nut (2) of breather assembly (1) on the top of the
fuel tank.
2.
Remove cover (3).
3.
Replace breather element (4) with a new one.
4.
Install cover (3) and nut (2).
METHOD FOR REPLACING PILOT FIL
TER ELEMENT
WARNING
Immediately after the engine is stopped, its parts and oil are still very hot, and may cause burn injury.
Accordingly
, wait until they have cooled down before starting the work.
1.
Loosen the oil filler cap (F) slowly on the top of the hy-
draulic
tank to release the internal pressure in the hydraul-
ic tank.
2.
Remove the covers (1) and (2).
MAINTENANCE PROCEDURE MAINTENANCE
4-62
