BX1870,BX2370,BX2670,LA203A,LA243A,RCK48(P),RCK54(P),RCK60B,RCK60D,RCK54D, WSM
I-16
(2) RCK54D-26BX and RCK60D-26BX
NOTE
• *Bar tires are prohibited from driving over mower deck.
• **Remove the frame link when rear attachment is on.
• ***Remove the frame link when snow chain is on.
9Y1210855INI0019US0
Model RCK60D-26BX RCK54D-26BX
Suitable tractor BX2370, BX2670
Mounting method
Drive Over Quick-Joint, Parallel linkage
Drive over suspended linkage
Adjustment of cutting height Dial gauge
Cutting width
1524 mm
(60 in.)
1372 mm
(54 in.)
Cutting height 25 to 102 mm (1.0 to 4.0 in.)
Weight
Mower 115 kg (250 lbs) 103 kg (227 lbs)
Mower with frame
link
134 kg (295 lbs) 122 kg (269 lbs)
Blade spindle speed
44.1 r/s
(2647 rpm)
49.5 r/s
(2969 rpm)
Blade tip velocity
72.5 m/s
(14271 fpm)
73.8 m/s
(14527 fpm)
Blade length
523 mm
(20.6 in.)
475 mm
(18.7 in.)
Number of blades 3
Dimensions
Overall length
1000 mm
(39.4 in.)
928 mm
(36.5 in.)
Overall width
1930 mm
(76.0 in.)
1780 mm
(66.5 in.)
Overall height (Min.)
281 mm
(11.0 in.)
Tire Industrial, Turf*
KiSC issued 02, 2017 A

Kubota BX1870 Specifications

General

Engine Type	Diesel
Engine Power	18 hp
Transmission	Hydrostatic
Fuel Capacity	6.6 gallons
Wheelbase	55.1 inches
Type	Sub-Compact Utility Tractor
Engine	Kubota D722
PTO Power	13.5 hp
Number of Cylinders	3
Cooling	Liquid
Drive	4WD
Drive Type	4WD
Width	44.5 inches
Hydraulic System Type	Open center
PTO Speed	540 RPM
Displacement	0.719 L
Fuel Tank Capacity	6.6 gallons
Gears	Infinite (2-range) forward and reverse
Front Tire Size	18x8.5-10
Rear Tire Size	26x12-12
