GENERAL
BX1870,BX2370,BX2670,LA203A,LA243A,RCK48(P),RCK54(P),RCK60B,RCK60D,RCK54D, WSM
G-68
(2) Rear Ballast
Add weights to rear wheels if needed to improve traction or for stability. The amount of rear ballast should be
matched to job and the ballast should be remove when it is not needed.
The weight should be added to the tractor in the form of liquid ballast.
9Y1210855GEG0089US0
Liquid Ballast in Rear Tires
1. Water and calcium chloride solution provides safe economical
ballast. Used properly, it will not damage tires, tubes or rims.
2. The addition of calcium chloride is recommended to prevent the
water from freezing.
3. Use of this method of weighting the wheels has the full approval
of the tire companies.
• Do not fill tires with water or solution more than 75 % of full
capacity (to the level of valve stem at 12 o'clock position).
• To avoid damage of transmission, do not use rear wheel
weights and liquid ballast at the same time.
9Y1210855GEG0090US0
Attaching Injector
1. Lift the rear tires off the ground.
2. Turn the tire so that the air valve is at the top.
3. Remove the air valve, and attach the injector. (Code No.
07916-52511)
9Y1210855GEG0091US0
Tire sizes
24 × 12.00 – 12
(BX1870D)
26 × 12.00 – 12
(BX2370D and
BX2670D)
Slush free at −10 °C (14 °F)
Solid at −30 °C (−22 °F)
[Approx. 1 kg (2 lbs) CaCl
2
per
4 L (1 gal.) of water]
35 kg
(77 lbs)
45 kg
(99 lbs)
Slush free at −24 °C (−11 °F)
Solid at −47 °C (−52 °F)
[Approx. 1.5 kg (3.5 lbs) CaCl
2
per 4 L (1 gal.) of water]
38 kg
(84 lbs)
50 kg
(110 lbs)
Slush free at −47 °C (−53 °F)
Solid at −52 °C (−62 °F)
[Approx. 2.25 kg (5 lbs) CaCl
2
per 4 L (1 gal.) of water]
44 kg
(97 lbs)
56 kg
(123 lbs)
(1) Air
(2) Water
(3) Valve Stem
(A) Correct: 75 % Full Air
Compresses Like A Cushion
(B) Incorrect: 100 % Full
Water Can Not Be Compressed
(1) Injector (2) Hose
