Lenze EPM-T110 User Manual

Parameterising analog modules
Diagnostic data
12
Parameter setting
12.3
12.3.2
l
12.3-6
EDSPM-TXXX-3.0-04/2004
12.3.2 Diagnostic data
If the diagnostic alarm is activated in byte 0 of the parameter data, the diagnostic
data in the emergency telegram are transmitted to the master (see chapter
”Diagnostics”,section”Emergency telegram”).1
The following bytes are available for diagnostic data:
Byte Assignment
0 Bit 0
Module monitoring
0
B
i
t
0
0Nofault
1 Module fault
Bit 1 Consistently at 0
Bit 2
External error
B
i
t
2
0 No error
1 External error
Bit 3
Error at inputs and / or outputs, respectively
B
i
t
3
0 No error
1 Error at at least one input and / or output, respectively
Bits 4 ... 7 Reserved
1 Bits 0 ... 3
Module type
1
B
i
t
s
0
.
.
.
3
0101 Analog module
Bit 4
Information on i nputs and / or outputs, respectively
B
i
t
4
0 No information available
1 Information available
2 Reserved
3 Reserved
The following bytes with fixed assignment are available for diagnostic data:
Byte Assignment
0 Bit 0
Module monitoring
0
B
i
t
0
0Nofault
1 Module fault
Bit 1 Reserved
Bit 2
External error
B
i
t
2
0 No error
1 External error
Bit 3
Error at inputs and / or outputs, respectively
B
i
t
3
0 No error
1 Error at at least one input and / or output, respectively
Bit 4
Supply error
B
i
t
4
0 No error
1 No external supply voltage
Bits 5 ... 6 Reserved
Bit 7
Wrong parameters
B
i
t
7
0 No error
1 Wrong parameters i n the module
1 Bits 0 ... 3
Module type
1
B
i
t
s
0
.
.
.
3
0101 Analog module
Bit 4
Information on i nputs and / or outputs, respectively
B
i
t
4
0 No information available
1 Information available
2 Reserved
3 Reserved
4xanalog input
4xanalog output
4xanalog input /output
