Lenze EPM-T110 User Manual

Parameterising 2/4xcounter module
Measuring the pulse width with GATE, fref programmable (modes 21 and 22)
12
Parameter setting
12.4
12.4.12
l
12.4-32
EDSPM-TXXX-3.0-04/2004
12.4.12 Measuring the pulse width with GATE, f
ref
programmable (modes 21 and 22)
1
2
3
4
5
6
7
8
9
10 GND
+24VDC
IN1 (RES)
IN2 (PULSE)
IN3 (GATE)
Out0
Counter 0
Counter 1
IN4 (RES)
IN5 (PULSE)
IN6 (GATE)
Out1
epm-t098
Fig. 12.4-41 Terminal assignment of the 2/4xcounter in the modes 21 and 22
The pulse widths of the signal at the input IN2 / IN5 (PULSE) are measured with a
programmabletimebase(f
ref
,seefigure“Counter access”).
The modules differ in having different counting directions:
Mode 21: Upcounter.
Mode 22: Downcounter
The measuring process is enabled with a HIGH level at input IN3 / IN6 (GATE).
The measuring process starts with a HIGH-LOW edge at input IN2 / IN5 (PULSE)
and ends with the LOW-HIGH edge.
A LOW-HIGH edge of the measured signal stores the pulse width with the unit
1/f
ref
. This result can be found and read out in the data output range until the next
result appears.
During the counting process, a LOW level must be applied to input IN1 / IN4 (RES).
A HIGH level deletes the counter.
Output OUT0 / OUT1 has no function.


 Note!
The measuring process is terminated only if a HIGH level is
applied at input IN3 / IN6 (GATE) for the complete duration of the
measuring process.
Terminal assignment
GATE/CLK signal
PULSE signal
RES signal
OUT signal
