The I/O system IP20
1
Preface
1.2
l
1.2-1
EDSPM-TXXX-3.0-04/2004
1.2 The I/O system IP20
Automation is playing an ever more important part in the operation of machines
and systems. The increasing number of peripherals has increased the amount of
wiring required. This is where distributed I/O systems bring order to the chaos.
Lenze has developed two new product concepts with IP20 protection which are
suitable for both basic digital applications and more complex automation tasks.
The modular system
Lenze can now provide you with a modular system for complex automation
applications, consisting of three components: a gateway, electronic modules and
a backplane bus. The key element is the gateway which processes all process data
traffic via the system bus (CAN) or CANopen. An internal backplane bus is also
used for the in-station communication between process and parameter data, as
well as diagnostics data.
The compact system
This system comprises a range of compact products with a fixed number of digital
inputs and outputs. The integrated gateway serves as a communication interface
which processes the complete process data traffic via system bus (CAN) or
CANopen.
Application as of version Note
Global Drive Control
4.4 Device data are only available after a software update.
4.5 Device data are available, exc ept for the follo wing modules of the
modular system:
•
”16×digital input”, ”16×digital output”, ”4×analog
input/output”, ”SSI interface”, ”1×counter/16×digital input”
After a software update, device data are available for all modules.
Drive Developer Studio
1.4 Libraries are only a vail a bl e after a software update.
2.1 Libraries are avail a bl e, except for the following modules of the
modular system:
•
”16×digital input”, ”16×digital output”, ”4×analog
input/output”, ”SSI interface”, ”1×counter/16×digital input”
After a software update, libraries are available for al l modules.
The system
The I/O system IP20 is
supported by
