Parameterising 2/4xcounter module

4 × 16 bit counter (modes 8 ... 11)

Parameter setting

12.4

12.4.6

12.4-15

EDSPM-TXXX-3.0-04/2004

epm-t081

Fig. 12.4-21 Counter access of the 2/4xcounter in the modes 8 ... 11

CLK 0.1

Counter 0.1

FFFE

0001 0002 0003 0004 0005 0006 0007 0008

FFFF 0000 0001 0002 0003 0004 0005

TclH2d

Tt0H

Tt0L

CLK 0.2

Counter 0.2

epm-t080

Fig. 12.4-22 Signal characteristic of 2/4xcounter in mode 8 considering as example the counters

0.1 and 0.2

Counter access

Signal characteristic
