12.6 Parameterising 1xcounter/16xdigital input module
12.6.1 Parameter data
The mode of operation of the internal counter can be determined by assigning a
mode via the parameter data.
For the 1xcounter/16xdigital input one byte of parameter data is available, which
is assigned via SDOs.
Depending on the plug-in station, the module is parameterised via the indices
3001
h
... 3010x
h
(max. 8 counter modules). The parameter data are stored in the
subindex 1.
epm-t176
Fig. 12.6-1 Display of the parameter data of 1xcounter/16xdigital input
The parameter data follow the assignment below:
Byte Assignment Lenze setting
0 Counter mode
00
h
Encoder with 4 edges
00
h
01
h
32-bit counter
h
02
h
Clock up/clock down evaluation
03
h
Measuring the frequency
04
h
Measuring the period
05
h...
FF
h
reserved


 Note!
Store changed parameters in the EEPROM via index I2003
h
.The
settings are maintained after switching off the supply voltage.
