Configuration
Function blocks
Master frequency processing (DFSET)
8
8.2
8.2.5

8.2-19
EDSVF9333V EN 3.0-06/2005
IMPORTANTPossible settingsCode
SelectionLenzeNameNo.
C0520

CFG: IN 1000 FIXEDPHI-0  Selection list 4 Configuration of input signal,
function block DFSET
z Input of speed / phase setpoint
signal
 8.2-18
C0521

CFG: VP-DIV 1000 FIXED0%  Selection list 1 Configuration of analog input
signal, function block DFSET
z Signal for numerator of
stretching factor
z 100 % = 16384 inc
C0522

cfg: rat-div 1000 FIXED0%  Selection list 1 Configuration of analog input
signal, function block DFSET
z Signal for numerator of
gearbox factor
z 100 % = 16384 inc
C0523

cfg: A-trim 1000 FIXED0%  Selection list 1 Configuration of analog input
signal, function block DFSET
z Signal for phase trimming via
offset multiplier (C0529)
z 100 % = 16384 inc
C0524

cfg: n-trim 1000 FIXED0%  Selection list 1 Configuration of analog input
signal, function block DFSET
z Signal for speed trimming
z Signal in [%] of C0011
C0525

cfg: 0-pulse 1000 FIXED0  Selection list 2 Configuration of digital input
signal, function block DFSET
z Signal for one-time zero pulse
activation
z HIGH = release for zero pulse
synchronisation
C0526

CFG: RESET 1000 FIXED0  Selection list 2 Configuration of digital input
signal, function block DFSET
z Signal for reset of integrators
z HIGH sets
– Position difference = 0
–DFSET-PSET=0
– DFSET-PSET2=0
C0527

CFG: SET 1000 FIXED0  Selection list 2 Configuration of digital input
signal, function block DFSET
z HIGH = Set phase integrators
to equal values
z LOW-HIGH edge sets
DFSET-PSET = 0
z HIGH-LOW edge sets
DFSET-PSET to the current
value of MCTRL-PHI-SET
z DFSET-SET has a higher priority
than DFSET-RESET
C0528 -2
.
10
9
{1} 2
.
10
9
Function block DFSET
z Display only
 8.2-18
1 DIS: 0-pulse A Phase difference between two
zero pulses
2 DIS: Offset Offset = C0523 × C0529 + C0252
