Lenze EVF9324 User Manual

Configuration
Code table
8
8.3

8.3-32
EDSVF9333V EN 3.0-06/2005
IMPORTANTPossible settingsCode
SelectionLenzeNameNo.
C0529 Multip offset 1 -20000 {1} 20000 Offset multiplier, function block
DFSET
z Multiplier for the phase offset
(C0252)
 8.2-18
C0530 DF EVALUATION 0
0 with factor With gearbox
factor
Master frequency evaluation,
function block DFSET
z Evaluation of the setpoint
integrator
1 no factor Without gearbox
factor
C0531 Act 0 div 1 1 {1} 16384 Actual zero pulse divisor, function
block DFSET
C0532 0-pulse/TP 1
1 0-pulse Index pulse
Zero pulse / touch probe,
function block DFSET
z Zero pulse of the feedback
system or touch probe
2 Touch probe Touch probe
C0533 Vp denom 1 1 {1} 32767 Gain factor of denominator V
p
,
function block DFSET
C0534 0pulsefct 0
Zero pulse function, function
block DFSET
z Synchronising the drive
 8.2-18
0 inactive Inactive
1 Continuous Continuous
synchronisation,
correction in the
shortest possible
way
2 Cont. switch Continuous
synchronisation,
correction in the
shortest possible
way
After a LOW-HIGH signal to
DFSET-0-pulse, the zero track is
synchronised once
10 Once, fast way One-time
synchronisation,
correction in the
shortest possible
way
11 Once, CW One-time
synchronisation,
correction in
direction of
rotation to the
right
12 Once, CCW One-time
synchronisation,
correction in
direction of
rotation to the
left
13 Once, 2*0-pulse One-time
synchronisation,
correction is
detected from
setpoint pulse
and actual pulse
and corrected to
the corresponding
direction
C0535 Set 0 Div 1 1 {1} 16384 Desired zero pulse divisor,
function block DFSET
 8.2-18
