Configuration
Code table
8
8.3
8.3-3
EDSVF9333V EN 3.0-06/2005
IMPORTANTPossible settingsCode
SelectionLenzeNameNo.
C0010 N
min
0 0 {1 rpm} 36000
z Reference value
for the absolute
and relative
setpoint selection
for the
acceleration and
deceleration
times
z C0059 must be
set correctly
z Set C0010 <
C0011
z C0010 is only
effective in case
of analog setpoint
selection via AIN1
Important: For
parameter setting
via interface, major
changes in one step
should only be made
when the controller
is inhibited.
Minimum
speed
6.10-1
C0011 N
max
3000 0 {1 rpm} 36000 Maximum
speed
C0012 TIR (ACC) 5.00 0.00 {0.01 s} 9999.90 Acceleration time T
ir
of the main
setpoint
z Refers to speed change
0 ... C0011
6.10-3
C0013 TIF (DEC) 5.00 0.00 {0.01 s} 9999.90 Deceleration time T
if
of the main
setpoint
z Refers to speed change
0 ... C0011
C0014 V/f charact. 0
Characteristic in the V/f
characteristic control mode
8.2-25
0 Linear Linear V/f characteristic
1 square Square V/f characteristic
C0015 Rated freq 50 10 {1 Hz} 5000 V/f-rated frequency
In C0015 you can set a base
frequency which differs from the
rated motor frequency (C0089)
z Lenze setting: C0015 = C0089
z Changing C0086 or C0089
overwrites the value in C0015
8.2-25
C0016 Umin boost 0.00 0.00 {0.01 %} 100.00 U
min
boost (FCODE)
z C0016=1%correspondstoa
boostof1%oftherated
motor voltage (C0090)
z Code is freely configurable
6.8-4
C0017 FCODE (Qmin) 50 -36000 {1 rpm} 36000 Q
min
-switching threshold
(FCODE)
z Programmable speed
threshold
z If the current speed is < C0017,
CMP1-OUT is activated.
z Freely configurable code
