Configuration
Function blocks
Internal motor control with V/f characteristic control (MCTRL1)
8
8.2
8.2.6
8.2-29
EDSVF9333V EN 3.0-06/2005
IMPORTANTPossible settingsCode
SelectionLenzeNameNo.
C0078 Tn slip CTRL 100 1 {1 ms} 6000 Integral-action time of slip
controller
z Filter time for slip
compensation (C0021)
z Only active with V/f
characteristic control
8.2-25
C0086
Mot type Æ Motor selection list Motor type selection
Æ depending on the controller
used
z Motor selection in C0086 sets
the corresponding parameters
in C0021, C0022, C0081, C0087,
C0088, C0089, C0090, C0091
6.6-1
C0087
Mot speed Æ 50 {1 rpm} 36000 Rated motor speed
Æ depending on C0086
z Motor selection in C0086 set
the corresponding rated motor
speed in C0087
z Change of C0087 sets
C0086 = 0
6.6-1
C0089
Mot frequency Æ 10 {1 Hz} 5000 Rated motor frequency
Æ depending on C0086
z Motor selection in C0086 sets
the corresponding rated motor
frequency in C0089
z Change of C0089 sets
C0086 = 0
6.6-1
C0090
Mot voltage Æ 0 {1 V} 1000 Rated motor voltage
Æ depending on C0086
z Motor selection in C0086 sets
the corresponding rated motor
voltage in C0090
z Change of C0090 sets C0086 =
0
6.6-1
C0095
Mot Io Æ 0.00 {0.01 A} 1000.00 Motor magnetising current
Æ depending on C0086, C0088
and C0091
z Change of C0086, C0088 and
C0091 sets C0095 to the Lenze
setting
z Change of C0095 sets
C0086 = 0
6.6-1
6.11-5
C0105 QSP Tif 5.00 0.00 {0.01 s} 999.90 Quick stop deceleration time
z The deceleration time refers to
a speed variation of C0011 ... 0
8.2-25
8.2-48
C0107 Holding time 0.00 0.00 {0.01 s} 9999.90 Hold time for automatic DC
injection braking (Auto-GSB)
8.2-25
8.2-48
C0132
Controller
enable fly
delay
Æ 0 {1 ms} 9999 Minimum time for controller
inhibit with active flying restart
circuit, delays the start of the
flying restart process after
controller enable
Æ depending on C0082, C0086,
C0087, C0088, C0089, C0090,
C0091, C0092
A change of one of the codes
resets C0132 to the minimum
time of the selected motor
z Thetimeisderivedfromthe
double rotor time constant
8.2-25
8.2-48
