Page #315 background image
Configuration
Code table
8
8.3
8.3-6
EDSVF9333V EN 3.0-06/2005
IMPORTANTPossible settingsCode
SelectionLenzeNameNo.
C0040 Ctrl enable 0
Controller enable
z Controller can only be enabled
if X5/28 = HIGH
6.4-1
0 Ctrl inhibit Controller inhibited
1 Ctrl enable Controller enabled
C0042 DIS: QSP
Quick stop
z Display only
8.2-25
8.2-48
0 QSP inactive Quick stop is not active
1 QSP active Quick stop is active
C0043 Trip reset 0
0 no/trip reset Reset actual error
1 trip active There is an error TRIP
C0045 DIS: act JOG
0 Nset active Nset is active
Active JOG setpoint for the speed
setpoint conditioning, function
block NSET
z Display of the activated fixed
speed
See System
Manual
(extension)
1 JOG1 JOG setpoint 1
2 JOG2 JOG setpoint 2
... ... ...
15 JOG15 JOG setpoint 15
C0046 DIS: N -199.9
9
{0.01 %} 199.99 Main setpoint for the speed
setpoint conditioning, function
block NSET
z Read only
C0049 DIS: NADD -199.99 {0.01 %} 199.99 Additional setpoint, function
block NSET
z Read only
See System
Manual
(extension)
C0050 MCTRL-NSET2 -100.0
0
{0.01 %} 100.00 Speed setpoint, function block
MCTRL
z Display of the speed in [%] of
C0011
8.2-25
8.2-48
C0051 MCTRL-NACT -36000 {1 rpm} 36000 Actual speed value, function
block MCTRL
z Display only
8.2-25
8.2-48
C0052 MCTRL-UMOT 0 {1 V} 800 Motor voltage, function block
MCTRL
z Display only
z MCTRL-VACT = 100 % = C0090
8.2-25
8.2-48
C0053 Ug-voltage 0 {1 V} 900 DC-bus voltage, function block
MCTRL
z Display only
z MCTRL-DCVOLT = 100 % =
1000 V
8.2-25
8.2-48
C0054 IMot 0.0 {0.1 A} 500.0 Current motor current, function
block MCTRL
z Read only
z MCTRL-IACT = 100 % = C0022
8.2-25
8.2-48
C0056 MCTRL-MSET2 -100.0
0
{0.01 %} 100.00 Read only. The output signal
depends on the operating mode:
z Current motor current in case
of V/f characteristic control,
function block MCTRL1
z Torque setpoint in case of
vector control, function block
MCTRL2
8.2-25
8.2-48
