12.2.2 Operation with increased rated power
9300 vector type EVF9321 EVF9322 EVF9323 EVF9324
Accessories Order No.
Mains choke ELN3-0700H003 ELN3-0450H004 ELN3-0250H007 ELN3-0160H012
Built-on mains filter
Limit class A EZN3A2400H002 EZN3A1500H003 EZN3A0750H005 EZN3A0400H009
Limit class B EZN3B2400H002 EZN3B1500H003 EZN3B0750H005 EZN3B0400H009
Motor filter ELM3-030H004 ELM3-030H004 ELM3-014H010 ELM3-007H025
Sinusoidal filter EZS3-002A001 EZS3-004A001 EZS3-006A001 EZS3-009A002
Brake chopper EMB9352-E EMB9352-E EMB9352-E EMB9352-E
Brake resistor ERBM470R050W ERBM470R100W ERBM370R150W ERBD180R300W
Shield connection
Control cable EZZ0015 EZZ0015 EZZ0015 EZZ0015
Motor cable EZZ0016 EZZ0016 EZZ0016 EZZ0016
Mounting set for
push-through
technique
EJ0036 EJ0036 EJ0037 EJ0037
9300 vector type EVF9325 EVF9327 EVF9328 EVF9329
Accessories Order No.
Mains choke ELN3-0120H025 ELN3-0075H045 ELN3-0055H055 ELN3-0055H055
Footprint mains filter – E82ZN22334B230 E82ZN30334B230 –
Built-on mains filter
Limit class A EZN3A0300H013 EZN3A0080H042 EZN3A0060H054 EZN3A0055H060
Limit class B EZN3B0250H015 EZN3B0080H042 EZN3B0055H060 EZN3B0055H060
Motor filter ELM3-007H025 ELM3-004H055 – –
Sinusoidal filter EZS3-017A001 – – –
Brake chopper EMB9352-E EMB9352-E EMB9352-E EMB9352-E
Brake resistor ERBD100R600W ERBD033R02K0 ERBD022R03K0 ERBD018R03K0
Shield connection
Control cable EZZ0015 EZZ0015 EZZ0015 EZZ0015
Motor cable EZZ0016 EZZ0017 EZZ0017 EZZ0017
Mounting set for
push-through
technique
EJ0038 EJ0011 EJ0011 EJ0011
9300 vector type EVF9330 EVF9331 EVF9332 EVF9333
Accessories Order No.
Mains choke ELN3-0027H105 ELN3-0022H130 ELN3-0017H170 ELN3-0014H200
Footprint mains filter E82ZN55334B230 – E82ZN90334B230 –
Built-on mains filter
Limit class A EZN3A0030H110 EZN3A0030H110 EZN3A0022H150 EZN3A0017H200
Limit class B EZN3B0030H110 EZN3B0030H110 EZN3B0022H150 EZN3B0017H200
Brake chopper 2 × EMB9352-E 2 × EMB9352-E 3 × EMB9352-E 3 × EMB9352-E
Brake resistor 2 × ERBD022R03K0 2 × ERBD018R03K0 3 × ERBD022R03K0 3 × ERBD018R03K0
Shield connection of
control cable
EZZ0015 EZZ0015 EZZ0015 EZZ0015
Mounting set for
push-through
technique
EJ0010 EJ0010 EJ0009 EJ0009
