Lenze EVF9324 User Manual

Configuration
Code table
8
8.3

8.3-5
EDSVF9333V EN 3.0-06/2005
IMPORTANTPossible settingsCode
SelectionLenzeNameNo.
C0026
-199.99 {0.01 %} 199.99
Free control code FCODE 26/1
and FCODE26/2
 6.5-4
See System
Manual
(extension)
1 FCODE (offset) 0.00 Offset of AIN1 (X6/1, X6/2)
2 FCODE (offset) 0.00 Offset of AIN2 (X6/3, X6/4)
C0027
-199.99 {0.01 %} 199.99
Free control code FCODE 27/1
and FCODE27/2
1 FCODE (GAIN) 100.00 Gain AIN1 (X6/1, X6/2)
z 100 % = gain 1
2 FCODE (GAIN) 100.00 Gain AIN2 (X6/3, X6/4)
z 100 % = gain 1
C0030 DFOUT CONST 3
0 256 inc/rev
Function block DFOUT
z Setting of the constant
(increments per revolution) f or
the master frequency output
X10
 8.2-8
1 512 inc/rev
2 1024 inc/rev
3 2048 inc/rev
4 4096 inc/rev
5 8192 inc/rev
6 16384 inc/rev
C0032 FCODE
GEARBOX
1 -32767 {1} 32767 Gearbox factor - numerator of
the function block DFSET
z Freely configurable code
 8.2-18
C0033 GEARBOX
DENOM
1 1 {1} 32767 Gearbox factor - denominator of
the function block DFSET
 8.2-18
C0034 Mst current 0
0 -10 V ... +10 V
Voltage / current range for
analog signals at input X6/1,
X6/2
z Observe jumper position of X3
 5.9-8
 6.5-4
1 4 mA ... 20 mA
2 -20 mA ... +20 mA
C0036 DC brk value 0.0 0.0 {0.1 A} - Set DC braking current
Æ depends on the controller
 8.2-25
 8.2-48
C0037 Set-value rpm 0 -36000 {1 rpm} 36000 Setpoint selection
C0038 0 {1 rpm} 36000 Suppress speed ranges, function
block NLIM1
z Speed ranges are only run
through dynamically
z Static behaviour in the
inhibited range is suppressed
See System
Manual
(extension)
1 N1start 0
Suppress speed range 1
2 N1stop 0
3 N2start 0
Suppress speed range 2
4 N2stop 0
5 N3start 0
Suppress speed range 3
6 N3stop 0
C0039 -36000 {1 rpm} 36000
JOG setpoints for the speed
setpoint conditioning, function
block NSET
z Parameter setting of the fixed
speeds (JOG setpoints)
z Activation via binary coding of
digital input signals in
C0787/1 ... C0787/4
z For coding see description of
function block NSET
See System
Manual
(extension)
1 JOG SET-VALUE 1500
2 JOG SET-VALUE 1000
3 JOG SET-VALUE 500
4 JOG SET-VALUE 200
5 JOG SET-VALUE 100
6 JOG SET-VALUE 50
7 JOG SET-VALUE 25
8 JOG SET-VALUE 10
9 JOG SET-VALUE 5
10 JOG SET-VALUE 0
... ... ...
15 JOG SET-VALUE 0
