EDSVF9333V EN 3.0-06/2005
IMPORTANTPossible settingsCode
SelectionLenzeNameNo.
C0135 Control word 0
Bit Assignment
Control word, function block AIF
z Decimal control word when
networked via automation
interface AIF
z 16-bit information, binary
coded
See System
Manual
(extension)
0 reserved
1 reserved
2 reserved
3 Quick stop
4 reserved
5 reserved
6 reserved
7 reserved
8 Operation i nhibited
9 Controller inhibit
10 TRIP SET
11 Trip reset
12 reserved
13 reserved
14 reserved
15 reserved
C0136 Display of the control words in
C0135, AIF-IN and CAN-IN1
See System
Manual
(extension)
1 Ctrl wrd C135 Control word C0135
2 Ctrl wrd CAN Control word CAN
3 Ctrl wrd AIF Control word AIF
C0140

select direct 0
Search direction during flying
restart process
z Positive direction of rotation:
The motor rotates in CW
direction with view on the
motor shaft
z Negative direction of rotation:
The motor rotates in CCW
direction with view on the
motor shaft
 8.2-25
 8.2-48
0 NSET Only search in the direction of the
applied setpoint
1 inv. Nset Only search against the direction
of the applied setpoint
2 pos. Only search in positive direction
of rotation
3 neg. Only search in negative direction
of rotation
4 Both, Nset Search at first in the direction of
the applied setpoint and then
against the direction
5 Both,inv.Nset Search at first against the
direction and then in the
direction of the applied setpoint
6 Both pos. Search at first in positive then in
negative direction of rotation
7 Both neg. Search at first in negative then in
positive direction of rotation
C0141 FCODE (setval) 0.00 -199.9 {0.01 } 199.99 Main setpoint, freely
configurable code (FCODE)
z Used as main setpoint in the
basic configurations
C0005 = xxx1
