Freez
18-2
18.3 Unfreezing Waveforms
To unfreeze the frozen waveforms, you can either:
îš„ Select the
button at the upper right corner of the [Freeze] menu, or
îš„ Select the
hardkey on the monitor’s front or the on-screen QuickKey again, or
îš„ Perform any other action that can cause the screen to be readjusted or open a menu, such
as plugging in or out a module, pressing the
hardkey, etc.
18.4 Recording Frozen Waveforms
1. In the [Freeze] menu, select, in turn, [Wave 1], [Wave 2] and [Wave 3] and then select
your desired waveforms.
2. Select the [Record] button. The selected waveforms and all numerics at the frozen time
are printed out by the recorder.
