Calculations
20-10
îš‹ If a calculated value is outside the range, its background will highlight in yellow.
You can select [Range] to view its normal range in the unit field. For those who
are within the range, their unit fields appear blank.
îš‹ Invalid values are displayed as [---].
In the [Hemodynamic Calculation] window, you can:
îš„ Trigger a recording by selecting the [Record] button. The currently displayed renal
calculations are printed out by the recorder.
îš„ Review the previously performed calculations by selecting [Review].
îš„ Switch to other calculation window by selecting [Other Calcs] and then select the
calculation you want.
20.5.2 Entered Parameters
Abbreviation Unit Full spelling
C.O. L/min cardiac output
HR bpm heart rate
PAWP mmHg pulmonary artery wedge pressure
Art Mean mmHg artery mean pressure
PA Mean mmHg pulmonary artery mean pressure
CVP mmHg central venous pressure
LV_D mm left ventricular diameter
Height cm height
Weight kg weight
