Review
19-2
19.2 Reviewing Graphic Trends
In the [Review] menu, select [Graphic Trends] to access the following window.
A. Parameter combo box B. Slider C. Parameter value
D. Parameter scale E. Graphic trends F. Time axis
In this review window:
îš„ To select parameters for viewing, you can either:
îš‹ Select respective parameter combo boxes and then select your desired parameters,
or
îš‹ Select [Trend Group] and then select a group from the popup list, or
îš‹ Select [Select Parameter>>] and then select your desired parameters from the
popup menu.
îš„ You can set the start time of the trends you want to view by selecting [Start Time].
B
A
E
F
C
D
