Chapter 7 Troubleshooting Tables
7.1 List of Board and IC Signals
Due to the nature of the schematic-generating program, signal names might be different when they
are not directly connected to the same point. The tables in this chapter provide a cross reference to
the various pinouts for these signals. Table 7-1 lists and provides links to each of the tables in this
chapter.
Table 7-1. List of Tables of Board and IC Signals
Table No. Table Name Page No.
7-2
Mainboard to main flex connector interface Pin-Out 7-2
7-3
Main Flex connector to main board connector interface Pin-Out 7-3
7-4
Side Button Flex connector Pin-Out 7-4
7-5
Top Control Flex connector Pin-Out 7-4
7-6
NFC Flex connector interface Pin-Out 7-5
7-7
Overall GPIO pin functions 7-5
7-8
Primary IC Reference Designator 7-13
