Motorola APX 3000 Detailed Service Manual

3-42 Theory of Operation: Controller
3.2.7 Encryption
The encryption circuitry is placed on the main board. The encryption circuitry is designed to digitally
encrypt and decrypt voice and ASTRO data in the APX 3000 radio. The Motorola Advanced Crypto
Engine (MACE) IC is the main component in the encryption design, and has some discrete support
circuitry along with the interfaces to the main board IC's (CPLD, OMAP, and Audio CODEC).
NOTE: The MACE IC is NOT serviceable. The information contained in this section is only intended
to help determine whether a problem is due to the MACE IC or the radio itself.
Figure 3-33 below shows the Encryption architecture for the APX 3000 radio.
Figure 3-33. APX 3000 Encryption Architecture
As shown in Figure 3-33 above, the encryption design consists of 5 blocks:
• MACE IC
• Key Loading
• Key Retention
•Tamper
• Key Zeroize.
MACE
(Secure IC)
OMAP
AUDIO
CODEC
SSI
SSI
Key
Zeroize
Tamper
Key
Fail
CPLD
CLK SSI GPIO
Key
Retention
