Motorola APX 3000 Detailed Service Manual

Debugging Fixture: Covert Board Debugging Fixture with Flexes, Housing and Display (Back) 9-3
9.4 Covert Board Debugging Fixture with Flexes, Housing and Display
(Back)
Figure 9-4. Covert Board Debugging Fixture with Flexes, Housing and Display (Back)
9.5 Debugging Fixture Set up
1. Remove the housing clamp and push down the slide clamp to assemble the front housing kit
(P/N: 0104052J79) on the fixture. Once the front housing kit is on the fixture, screw back the
housing clamp.
Figure 9-5. Remove the Housing Clamp
