Motorola APX 3000 Detailed Service Manual

Debugging Fixture: Covert Board Debugging Fixture (Front) 9-1
Chapter 9 Debugging Fixture
This chapter contains images of APX 3000 Covert Board Debugging Fixture (P/N: 66012036001)
used to debug the board.
The fixture needs to be assembled with flexes (P/N: 0104055J17, 0104055J18 and 0104052J74),
front housing kit (P/N: 0104052J79) and FSTN Display with Bezel (P/N: 72012008001) for the fixture
to function correctly.
9.1 Covert Board Debugging Fixture (Front)
Figure 9-1. Covert Board Debugging Fixture (Front)
