Theory of Operation
: Controller
3-41
T
able 3-7. GCAI Connector Pin Assignment
PIN
ASSIGNMENT
SIGNAL
1
GCAI_GPIO0 / PwrOn
2
GCAI_ONE_WIRE
3
GCAI_VBUS
_5V
4
GCAI_USB_P_GPIO1
/ TxDc / FillReq
5
GCAI_USB_N_GPIO2 / RxDc / FillData
6G
N
D
7
GCAI_SPKR_P / LineOut+
8
GCAI_SPKR_N / LineOut-
9
GCAI_RTS_GPIO_
3 / OTG-ID / FillSen
10
GCAI_MIC_P
1
1
GCAI_MIC_N
12
GCAI_CTS_GPIO_4 / KeyFail
/ FillClk
66
68
