4-2 Troubleshooting Procedures: Recommended Service Tools
4.2 Recommended Service Tools
Table 4-1 lists recommended service tools that can be used for PC board repairs at the component
level. For listings of additional service tools, service aids, and test equipment that are recommended
for all levels of service, refer to the APX 3000 basic service manual (see Related Publications).
Table 4-1. Recommended Service Tools
Motorola
Part Number
Description Application
PMLN6208_ Chassis Opener Used to disassemble chassis from housing
66012031001 Battery Adapter Used in place of battery to connect radio to an external
power supply.
66012075001 Vacuum Test Fixture To connect the vacuum/pressure hose to the radio.
NLN9839_ Vacuum Pump Kit Vacuum pump with gauge and vacuum hose. Requires
Vacuum Test Fixture (66012075001).
5880384G68 SMA to BNC Adapter Adapts radio’s antenna port to BNC cabling of test
equipment.
RVN5224_ Customer Programming Software
(CPS) and Tuner Software
CPS allows customer-specific programming of modes and
features. Tuner software required to perform alignment of
radio parameters.
PMKN4012_ Programming Cable Used to program the radio through Customer Programming
Software and Tuner Software.
PMKN4013_ Programming/Service Cable Used to program and service the radio through Customer
Programming Software and Tuner Software.
RLN4460_ Portable Test Set Used for radio performance checks. Connects to radio’s
universal connector and allows remote switching and signal
injection/outputs for test equipment measurements.
66012036001 APX 3000 Covert Board Debugging
Fixture
To be assembled with Flex, Debug (0104055J17), flex,
Extended Main (0104052J79), Assy, Flex, NFC
(0104052j74), front housing kit (0104052J79), and FSTN
Display with Bezel (72012008001).
