Motorola MCS 2000 Service Instructions

December 6, 2004 68P81083C20-D
xviii Mobile Radio Model Numbering System
List of Models
PRIVATE SYSTEMS RADIOS
MCS 2000 Model Family
Model Number Frequency Range Power Level Control Head Model Channel Spacing No. of Modes
M01JLM9PW6_N 136 - 162 MHz 50-100 Watts Model II, 1x14 digits 25/20/12.5 kHz 160
M01JLN9PW6A_N 136 - 162 MHz 50-100 Watts Model III, 2x14 digits 25/20/12.5 kHz 160
M01KHL9PW4_N 136 - 174 MHz 1-25 Watts Model I, 8 digits 25/20/12.5 kHz 48
M01KHM9PW5_N 136 - 174 MHz 1-25 Watts Model II, 1x14 digits 25/20/12.5 kHz 160
M01KHN9PW5_N 136 - 174 MHz 1-25 Watts Model III, 2x14 digits 25/20/12.5 kHz 160
M01KLM9PW6_N 146 - 174 MHz 50-100 Watts Model II, 1x14 digits 25/20/12.5 kHz 160
M01KLN9PW6_N 146 - 174 MHz 50-100 Watts Model III, 2x14 digits 25/20/12.5 kHz 160
M01RFL9PW4_N 403 - 470 MHz 1-10 Watts Model I, 8 digits 25/20/12.5 kHz 48
M01RFM9PW5_N 403 - 470 MHz 1-10 Watts Model II, 1x14 digits 25/20/12.5 kHz 160
M01RFN9PW5_N 403 - 470 MHz 1-10 Watts Model III, 2x14 digits 25/20/12.5 kHz 160
M01RHL9PW4_N 403 - 470 MHz 10-25 Watts Model I, 8 digits 25/20/12.5 kHz 48
M01RHM9PW5_N 403 - 470 MHz 10-25 Watts Model II, 1x14 digits 25/20/12.5 kHz 160
M01RHN9PW5_N 403 - 470 MHz 10-25 Watts Model III, 2x14 digits 25/20/12.5 kHz 160
M01RLM9PW6_N 403 - 470 MHz* 50-100 Watts Model II, 1x14 digits 25/20/12.5 kHz 160
M01RLN9PW6_N 403 - 470 MHz* 50-100 Watts Model III, 2x14 digits 25/20/12.5 kHz 160
M01SHL9PW4_N 450 - 512 MHz 10-25 Watts Model I, 8 digits 25/20/12.5 kHz 48
M01SHM9PW5_N 450 - 512 MHz 10-25 Watts Model II, 1x14 digits 25/20/12.5 kHz 160
M01SHN9PW5_N 450 - 512 MHz 10-25 Watts Model III, 2x14 digits 25/20/12.5 kHz 160
M01SKM9PW6_N 450 - 512 MHz 40-50 Watts Model II, 1x14 digits 25/20/12.5 kHz 160
M01SKN9PW6_N 450 - 512 MHz 40-50 Watts Model III, 2x14 digits 25/20/12.5 kHz 160
M01UGL6PW4_N 806 - 870 MHz 15 Watts Model I, 8 digits 20/25 kHz 48
M01UGM6PW6_N 806 - 870 MHz 15 Watts Model II, 1x14 digits 20/25 kHz 160
M01UGN6PW6_N 806 - 870 MHz 15 Watts Model III, 2X14 digits 20/25 kHz 160
M01UJL6PW4_N 806 - 870 MHz 30-35 Watts Model I, 8 digits 20/25 kHz 48
M01UJM6PW6_N 806 - 870 MHz 30-35 Watts Model II, 1x14 digits 20/25 kHz 160
M01UJN6PW6_N 806 - 870 MHz 30-35 Watts Model III, 2X14 digits 20/25 kHz 160
M01WGL4PW4_N 896-941 MHz 12 Watts Model I, 8 digits 12.5 kHz 48
M01WGM4PW6_N 896-941 MHz 12 Watts Model II, 1x14 digits 12.5 kHz 160
M01WGN4PW6_N 896-941 MHz 12 Watts Model III, 2X14 digits 12.5 kHz 160
M01WJL4PW4_N 896-941 MHz 30 Watts Model I, 8 digits 12.5 kHz 48
M01WJM4PW6_N 896-941 MHz 30 Watts Model II, 1x14 digits 12.5 kHz 160
M01WJN4PW6_N 896-941 MHz 30 Watts Model III, 2X14 digits 12.5 kHz 160

Motorola MCS 2000 Specifications

General

Brand	Motorola
Model	MCS 2000
Category	Radio
Language	English
