Motorola MCS 2000 Service Instructions

68P81083C20-D December 6, 2004
Specifications for UHF, 1-10 Watt and 10-25 Watt Radios xxv
Specifications for 15 Watt and 35 Watt Radios
All specifications are per Electronic Industries Association (EIA) 603 unless otherwise noted.
GENERAL RECEIVER TRANSMITTER
FCC Designation: 30-35W: AZ492FT5773
15W: AZ492FT5765
Temperature Range:
Operating: -30 to +60°C
Storage: -40 to +85°C
Power Supply:
Nominal Voltage: 13.6 V
Operating Voltage: 10.8-16.3 V
Current Drain, maximum values:
Stand-by: 0.45 A
Receive:
1.7 A with 7.5 W speaker
2.5 A with 13 W speaker
1.5 A with 4 W speaker
Transmit (15W): 6.5 A
Transmit (35W): 13.5 A
Off: 30 mA
Number of Modes:
Model I: Standard 48, optional 150
Model II, III: Standard 160, optional 250
Channel Spacing:
806-821 & 851-866MHz: 25 kHz
821-825 & 866-870MHz: 20 kHz
Mode of Operation: Simplex and Semi Duplex
Modulation: FM
Antenna Impedance: 50 ¾
Frequency Stability:
806-821 MHz & 851-866 MHz: ±2.5 ppm
821-825 MHz & 866-870 MHz: ±1.5 ppm
Dimensions (H/W/D):
1-25W Transceivers:
44x168x180 mm / 1.73”x6.61”x7.09”
25-50W Transceivers:
44x168x230 mm / 1.97”x6.61”x7.76”
Control Head I, Dash Mt.:
44x168x30 mm / 1.75”x6.61”x1.81”
Control Head II, III, Dash Mt.:
60x186x30 mm / 2.35”x7.33”x1.83”
Control Head II, III, Remote Mt.:
60x186x71 mm / 2.35”x7.33”x2.78”
Weight:
1-25 Watt Transceivers: 1.6 kg / 3.53 lbs
25-50 Watt Transceivers: 1.8 kg / 4.04 lbs
Control Head I, Dash Mt.: 152 g / 0.33 lbs
Control Head II, Dash Mt.: 233 g / 0.51 lbs
Control Head III, Dash Mt.: 229 g / 0.50 lbs
Frequency Range: 851-866MHz
866-870MHz
Maximum Frequency Separation: 18 MHz
Sensitivity:
20dB SINAD: 0.40 uV
12dB SINAD: 0.30 uV
Adjacent Channel Selectivity:
Model I: -75 dB
Models II & III: -80 dB
Spurious & Image Rejection:
Model I: -75 dB
Models II & III: -90 dB
Intermodulation:
Model I: -75 dB
Models II & III: -80 dB
Conducted Spurious Emission:
per FCC part 90
Audio Output:
4 W (internal, 16 ¾)
7.5 W or 13 W (external, 8 ¾/3.2 ¾)
Audio Response:
6 dB/octave +1/-3 dB at 300-3000 Hz
Distortion :4/7.5/13 W @:<5%
Frequency Range:
806-821 & 821-825MHz
(Talkaround) 851-866 & 866-870MHz
Maximum Frequency Separation: 63 MHz
RF Power: 15 Watts
30 or 35 Watts
Deviation, Maximum:
@806-821 & 851-866MHz: 5 kHz
@821-825 & 866-870MHz: 4 kHz
Spurious & Harmonics: -70 dBc
Audio Response:
6 dB/octave +1/-3 dB at 300-3000 Hz
Distortion:
<3% @ 60% of maximum deviation
Adjacent Channel Power (CEPT):
-60 dBc
Specifications subject to change without notice.
