Motorola MCS 2000 Service Instructions

December 6, 2004 68P81083C20-D
4-2 Test Mode and Error Codes: Test Mode
Figure 4-1. Dedicated Test Mode Keys on the Model I Faceplate
Figure 4-2. Dedicated Test Mode Keys on the Model II Faceplate
Figure 4-3. Dedicated Test Mode Keys on the Nodel III
RF/CH Test Mode Select
Pressing the scroll key alternates between the two Mode Select menus RF TEST and CH TEST. To
select either the RF or CH test menu press the dedicated select key while the desired menu is being
displayed.
TM1
TM2
TM2
TM1
123
456
789
*
0#
TM2
TM1
